HDD-1-24-S Refrigerator, Single Section, Stainless Steel Back Bar Direct Draw, Solid Door

24″ W X 30″ D X 39″ H
Electrical Specs
Electrical Connection: 5 – 15P NEMA, 115v/60/1, 10 ft. cord and plug, Energy Consumption: 1.32 Watts, Amperage: 2.5, Max Fuse/HACR Breaker: 15 A
Operating Limits
Ambient Temp Range: 45 – 100°F, Voltage Range: 104 – 126V, Control Setpoint Range: 33 – 38°F, Refrigerant: R-134a
Refrigeration Data
Nominal Compres. of 1056 BTU/hr at 1/6 HP, Heat Rejection: 1056 BTU/hr
Shipping Weight
175
Storage Specs
Interior Storage Capacity: 7.46ft3, Door Opening: 20.625″ W x 29.5″ H , Depth with Door fully extended: 53.375″ D, Keg Cushions Included: 1
Warranty
Three Years: Parts & Labor warranty on entire machine.

Overview and Features

The HDD-1-24-S Back Bar Direct Draw is a Single Section Refrigerator with a Solid Door is the perfect portable kegreator for any operation. It boasts an impressive net capacity of 7.46 cubic feet. The durable 1/6 HP motor that powers the compressor in the back of this unit ensures a free flowing air system throughout the cabinet and keeps the keg(s) cold. Engineered to maintain food safe temperatures in +100°F kitchens. Plus the lockable swing door is insulated with environmentally friendly, cfc free foamed in place polyurethane.

The durable stainless steel interior with reinforced threshold protects cabinet from loading/unloading keg damage. While the stainless steel exterior front, sides and rear, plus a 18 gauge stainless steel top includes a brushed aluminum glass rail for mug storage on top! The HDD-1-24-S includes 1 keg cushion, and comes standard with (4) 4″ casters (front 2 with brakes), it features (1) polished stainless steel insulated tower with (1) plated brass faucet. Made to Order. Cabinet fits: (1) 1/2 barrel, or (1) 1/4 barrel, or (2) slim 1/4 barrels, or (4) 1/6 barrels. The unit is ETL Safety (US & C) Listed, ETL Sanitation and includes a Five Years compressor warranty / Three Years parts and labor warranty.

[fusion_button link=”https://hoshizakiamerica.com/product/DD24-S/” color=”blue” size=”medium” type=”3d” shape=”square” target=”_self” title=”View New Model” gradient_colors=”|” gradient_hover_colors=”|” accent_color=”” accent_hover_color=”#5aabd6″ bevel_color=”” border_width=”1px” shadow=”yes” icon=”fa-exclamation-circle” icon_divider=”no” icon_position=”left” modal=”” animation_type=”0″ animation_direction=”down” animation_speed=”0.1″ class=”” id=””]REPLACED BY DD24-S[/fusion_button]

  • Dimensions: 24.88″ W x 30″ D x 39.38″ H
  • Net capacity of 7.46 cubic feet
  • Nominal Compres. of 1056 BTU/hr at 1/6 HP
  • Electrical consumption of 1.32 kWh/day at 2.5 Amps, 10 ft long cord with a 5 – 15P NEMA plug
  • Engineered to maintain food safe temperatures in +100°F kitchens
  • Includes (1) keg cushion to protect floor and allow air to circulate below kegs
  • One piece, vinyl coated steel handle with built-in lock
  • (1) polished stainless steel insulated tower with (1) plated brass faucet
  • Lockable swing door is insulated with environmentally friendly, CFC free foamed in place polyurethane
  • Rear breathing with internal drain, internal CO2 chain harness, and knockouts for gas line of for plumbing drain to outside of unit
  • Stainless Steel exterior front, sides and rear, plus a 18 gauge stainless steel top
  • Stainless steel interior with reinforced threshold protects cabinet from loading/unloading keg damage
  • R-134a refrigerant
  • Automatic “off cycle” defrost cycle
  • Brushed aluminum glass rail for mug storage on top
  • Includes 1 keg cushion
  • Cabinets walls and doors well insulated (2″ thick) and are designed to maintain interior temperatures between 33°F to 38°F
  • Standard with (4) 4″ Casters (front 2 with brakes)
  • Made to Order
  • 115v/60/1, 10 ft. cord and plug
  • Shipping Crate: 34.5″ L x 29″ D x 45.5″ H at 175 lbs
  • Cabinet fits: (1) 1/2 barrel, or (1) 1/4 barrel, or (2) slim 1/4 barrels, or (4) 1/6 barrels
  • Five Years compressor warranty, Three Years parts and labor warranty
