IM-50BAA-LM Square Cuber Icemaker, Air-cooled, Built in Storage Bin
Overview and Features
The IM-50BAA-LM is capable of producing approximately 50 lbs of individual square cubes. The square cube shape melts very slowly, chilling beverages with minimal dilution. This Air-cooled, Built in Storage Bin icemaker features Up to 22 lbs of built-in storage capacity* and its Small footprint can easily fit under a bar counter. The IM-50BAA-LM is Single phase, 115v/60/1, 6.5 ft. cord with NEMA 5-15 plug and uses R-134a refrigerant (6.0 oz. / 170 g). Please consult the Specification Sheet for additional details.*Rated in accordance with AHRI Standard 820(I-P). Capacity based on 100% of total volume x 30 lb/ft3 average density of ice.
PFAS Warning: This product contains: PTFE and Propane, 1,1,1,2,2,3,3-heptafluoro-3-[(1,2,2-trifluoroethenyl) oxy]-, polymer with 1,1,2,2-tetrafluoroethene. For more information about PFAS chemicals in this product, visit the California Safer Consumer Products website.
- Dimensions: 19-3/4″ W x 17-3/4″ D x 39- 1/2 ” H
- Up to 50 lbs of ice produced per 24 hours
- Up to 22 lbs of built-in storage capacity
- Produces individual clear, solid 1.9″ x 1.9″ x 2.3″ cubes
- Durable stainless steel exterior
- Front in, back out airflow
- Ice scoop included
- Foam injected polyurethane for insulation (HFC free)
- Small footprint can easily fit under a bar counter
- R-134a refrigerant (6.0 oz. / 170 g)
- Heat Rejection:1500 BTU/hr
- Ambient temperature range: 45 – 100°F
- Water temperature range: 45 – 90°F
- Water pressure: 10 – 113psig
- Voltage range: 104 – 127V
- 5 amps (15 Amp Max fuse)
- 15.7 kwh/100 lbs.@ 90/70
- Single phase, 115v/60/1, 6.5 ft. cord with NEMA 5-15 plug
- Clean ice and easy maintenance lead to longer unit life span
- Three Years: Parts & Labor warranty on entire machine.
- Five Years: Parts warranty on Compressor, air-cooled condenser coil.
